RELEASE FILM

Perforated release film is the best choice for vacuum forming's releasing.

  • UNION

Availability:
Quantity:
Inquire Add to Basket

Product Description
Specifications
Product Certification

Perforated release film has good gas permeability, high temperature resistance and isolation performance, it can (replace peel ply) be used in wind-power blades, yachts, plane seats and other vacuum forming (RTM) processes. Perforated release film is the best choice for vacuum forming's releasing.


Features:



7

Application

8

Infusion Process

9

Infusion Process


Product Specifications:


Items

UT-125

UT-170

Test Standard

Materials Type

Polyolefin, multi-layer

Polyolefin, multi-layer

------

Elongation at break

450%

350%

ASTM D 882

Tensile Strenth

35Mpa

35Mpa

ASTM D 882

Maximum using temperature

125℃

170℃

------

Application Resin Type

Compatible with most resin systems

Compatible with most resin systems

------

Thickness

30u or 50u

30u or 50u

------

Density

29g/m2 or 48g/m2

29g/m2 or 48g/m2

------

Color

Red or Blue

Red or Blue

------

Maximum Width

1.5m

1.5m

------




ISO 9001

ISO 9001

ISO 14001

ISO 14001

RS certification

RS Certification


TAK00001DV

TAK00001DV

certification 05 (1)

RoHS

Flame retardant report

Flame Retardant Report
